Where can I find documentation and specifications for the Elo E196429 COACh V Controller Chip?
The E196429 (CTR-COACH5-AT-CHP-00-R) is an Elo COACh V touch controller available as a standalone component.
The Elo Touch Solutions COACh V is a single LQFP-48 integrated circuit designed to interface with five-wire resistive touchscreens. It can automatically detect both the touchscreen configuration and the installed communication system.
Public-facing specifications and general information can be found on the product page:
https://www.elotouch.com/touchscreen-components-coach-at-controller-chip.html
⚠️ Important:
All detailed technical documentation for this part, including the full data sheet, is proprietary and provided only under a signed Non-Disclosure Agreement (NDA).
Customers who require access to this documentation should contact their Elo Sales representative to initiate the NDA process and request the appropriate materials.
All detailed technical documentation for this part, including the full data sheet, is proprietary and provided only under a signed Non-Disclosure Agreement (NDA).
Customers who require access to this documentation should contact their Elo Sales representative to initiate the NDA process and request the appropriate materials.
Please report any broken links by emailing support@elotouch.com and include a link to the knowledge article
