本文提供了Elo USB-C电缆的规格和引脚排列信息
如果您希望从第三方采购USB-C电缆，请参见下面的电气和线规规格。
- 向后兼容USB 2.0和USB 3.1
- 电源供电5V 3A/9V 3A/15V 1.8A/20V 1.35A
- 线规，请参见Elo的P/N: E710364电缆设计/线规
请参见下面的表格以获取关于USB-C电缆（E710364）的引脚排列信息。
| P1 (USB TypeC) | P2 (USB TypeC) | |
| GND | GND | |
| TX1+ | TX1+ | |
| TX1- | TX1- | |
| VBUS | VBUS | |
| CC1 | CC1 | |
| D+ | D+ | |
| D- | D- | |
| SBU1 | SBU1 | |
| VBUS | VBUS | |
| RX2- | RX2- | |
| RX+ | RX+ | |
| GND | GND | |
| GND | GND | |
| TX2+ | TX2+ | |
| TX2- | TX2- | |
| VBUS | VBUS | |
| CC2 | CC2 | |
| D+ | D+ | |
| D- | D- | |
| SBU2 | SBU2 | |
| VBUS | VBUS | |
| RX1- | RX1- | |
| RX1+ | RX1+ | |
| GND | GND |
