This article provides specifications for the barcode scanner that is integrated into the M50 Mobile Computer.

The M50 Handheld Computer is integrated with a Zebra SE4710-LM000R + SDL scan engine. Visit the product spec page HERE.



Barcode Scanner Supported symbologies

1D Symbologies

• UPC/EAN
• Bookland EAN
• UCC Coupon Code
• ISSN EAN
• Code 128
• GS1-128
• ISBT 128
• Code 39
• Trioptic Code 39
• Code 32
• Code 93
• Code 11
• Interleaved 2 of 5
• Discrete 2 of 5
• Codabar
• MSI
• Chinese 2 of 5
• Korean 3 of 5
• Matrix 2 of 5
• Inverse 1D
• GS1 DataBar
• Composite Codes

2D Symbologies

• PDF417
• MicroPDF417
• Data Matrix
• Data Matrix Inverse
• GS1 Data Matrix
• Maxicode
• QR Code
• MicroQR
• GS1 QR Code
• QR Inverse
• Aztec
• Aztec Inverse
• Han Xin
• Han Xin Inverse
• Grid Matrix
• DotCode

Postal Codes

• US Postnet
• US Planet
• UK Postal
• Japan Postal
• Australian Postal
• Netherlands KIX Code
• USPS 4CB/One Code/Intelligent Mail
• UPU FICS Postal

Decode ranges:

• M50 / M60+BCR (SE4710):
• Code 39 (4mil): 8.4cm-22.24cm.
• Code 128 (5mil): 7.1cm-20.8cm.
• Code 39 (5mil): 5.08cm-34.3cm.
• PDF417 (5mil): 7.9cm-21.3cm.
• DataMatrix (10mil): 7.4cm-25.7cm.
• UPCA (100%): 4.6cm-66.0cm.
• Code 39 (20mil): 5.08-76.2cm.
• Post-sale activation of software decode library shall be available using Zebra software decode license (software decode of camera scanning).
• Decode time spec is usually under 200ms on a good quality barcode.
• It shall work under sunlight and larger than 20k Lux. Ambient light on nonreflective paper barcodes. It actually depends on the material of the barcode.
