This article explains how to Add Carriage Return (Enter) on the 1st Generation 2D Barcode Scanner (E926356)
The 2D barcode scanner is set factory default to read all on one line. If you want the scanner to do a carriage return (enter) function after each barcode, see below steps.
How to add a Carriage Return (CR) or Horizontal Tab (HT) after each scan?
1. Before adding the desired suffix, scan the bar code ‘Clear all suffixes’.
a. To clear all suffixes scan the following bar code:
b. For ‘Enter” scan the following bar code:
c. For ‘TAB’ scan the following bar code:
Download a .pdf copy of the above from Honeywell HERE
