This article provides instructions for installing a rear facing display mounting kit on the EloPOS

Please see steps below for installing the rear facing display mounting kit onto the EloPOS units.

Included items EloPOS Rear Facing Display Mounting Kit, P/N: E835969

• Assembled Rear Facing Display Mount Module
• Quick Install Guide
• SCREW, M4X7, CROSS-RECESS PAN HEAD, BLACK, QTY.4
• SCREW, M4X10, CROSS-RECESS PAN HEAD, STAINLESS, QTY.3
• CABLE-CLAMP, QTY.1
• SCREW, M3X8 (8mm L MIN.), CROSS-RECESS PAN HEAD, BLACK, QTY.1
• Desiccant
• 1x 2 Feet USB-C Cable, P/N:E969524
  • (Note: the USB-C cable P/N: E969524 must be purchased separately when mounting kit is ordered)

Example below of rear facing display mounted to EloPOS unit:
